Regular Specification：

Model	Air flow (m3/h)	Fan whole pressure (pa)	Absorption Rate (%)	Box size（mm） （double stage filter、included fan）	Outlet size（mm）		Matched filter
					Air intake	Air outlet
BACH-3000	3000	＞700pa	65%~95%	700*700*1600 No access door，pull-out type	300*200	300*200	HACH-02870592292-4V/ 2 sets
BACH-16000	16000			1920*1300*1600 No access door，pull-out type	800*600	800*600	HACB-06100610292-4V/ 6 sets
BACH-6000	6000			1300*700*2400 Included access door	400*300	400*300	HACB-06100610292-4V/ 2 sets
BACH-12000	12000			1300*1300*2400 Included access door	500*400	500*400	HACB-06100610292-4V/ 4 sets
BACH-24000	24000			1920*1300*2400 Included access door	1000*800	1000*800	HACB-06100610292-5V/ 6 sets

◆It is made of the imported PTFE micropore filter membrane and the imported non-woven cloth or silkscreen supporting layer for folding.
◆Filter core’s outer cylinder,core column,cover are made of enhancement-mode polypropylene, each sealing part is used of the advanced fusion welding technology to form, not any adhesives.
◆The filter mambrane has strong hydrophobicity, it can be degermed absolutely in the moist or drying condition. It can be held back all the germ and phage(≥0.01µm）when filtering the gas.
◆It has strong chemical tolerance and heat stability, temperature resistance,impact resistance and corrosion resistance.
◆Large flow, low differential pressure,long service live
◆Integrity detection of each filter.

◆It is made of the imported PTFE micropore filter membrane and the imported non-woven cloth or silkscreen supporting layer for folding.

◆The degerm and filtering of in-out gas for Air compression,bioreactor,storage tank, dispensing pot.
◆The degerm and filtering of electronic industry's high purity gas and the organic solvent.
